V0 Flame Retardant Masterbatch For PP
Specification
This series of products is a high concentration phosphorus and nitrogen based halogen-free flame retardant masterbatch with PP carrier. It can withstand 0.8mm/UL-94 V-0 and UL746C (70℃ hot water immersion test for 168 hours), and has passed GWIT 750 ℃ and GWFI 960 ℃ hot wire tests.
This product has high environmental performance and can meet the requirements of the EU RoHS directive. The resulting flame retardant products have the characteristics of low density and low smoke generation.
Details
| Characteristic | FR-M8370A | FR-M8370B | FR-M8380B | FR-M8370D |
| Corresponding Flame Retardant |
XS-FR-8300 | XS-FR-8340 | XS-FR-8340 | XS-FR-8332 |
| Effective Content% | 70±0.5 | 70±0.5 | 80±0.5 | 70±0.5 |
| Volatile % | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 |
| Temperature Resistance |
260 | 250 | 250 | 260 |
| Precipitation Resistant | ★★★ | ★★★ | ★★★ | ★★★ |
| Others | Non Raintarced Weather Resistance |
Non Reinforced | Non Reinforced | Non Reinforced High Flow |
| Recommended addition | XS-FR-M8370A | XS-FR-M8370B | XS-FR-M8380B | XS-FR-M8370D | |||||||||
| Glass Fiber % | 0 | 20 | 30 | 0 | 20 | 30 | 0 | 10 | 30 | 0 | 10 | 30 | |
| Ho-PP | 0.8mm V-0 | 43 | —— | —— | 42 | —— | —— | 42 | —— | —— | 42 | —— | —— |
| 1.6mm V-0 | 36 | —— | —— | 36 | —— | —— | 37 | 38 | —— | 37 | 38 | —— | |
| 3.2mm V-0 | 32 | —— | —— | 28 | —— | —— | 28 | —— | —— | 28 | —— | —— | |
| Characteristic | FR-M8370E | FR-M8370F | FR-M8365AR | FR-M8375AP |
| Corresponding Flame Retardant |
XS-FR-8310 | XS-FR-8320 | XS-FR-8340 | APPII |
| Effective Content % | 70±0.5 | 70±0.5 | 70±0.5 | 70±0.5 |
| Volatile % | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 |
| Temperature Resistance |
280 | 270 | 250 | 260 |
| Precipitation Resistant | ★★★★★ | ★★★ | ★★★ | ★★★ |
| Others | Reinforced | PP Plate | Non Reinforced | Non Reinforced High Flow |
| Dosage % | FR-M8370E | FR-M8370F | FR-M8365AR | FR-M8375AP | |||||||||
| Padding % | 0 | 15 | 30 | 0 | 15 | 30 | 0 | 15 | 30 | 0 | 15 | 30 | |
| Co-PP | 0.8mm V-2 | 2.5 | —— | —— | 2.5 | —— | —— | 3 | —— | —— | 3 | 10 | —— |
| 1.6mm V-2 | 3 | —— | —— | 3 | —— | —— | 3.5 | —— | —— | 3.5 | 10 | —— | |
| 3.2mm V-2 | 3 | —— | —— | 3 | —— | —— | 3.5 | —— | —— | 3.5 | 10 | —— | |
| 0.8mm V-2 | 1 | —— | —— | 1 | 2-3 | 4-5 | 1 | 3 | —— | 1 | 6 | —— | |
| Ho-PP | 1.6mm V-2 | 1 | —— | —— | 1 | 2-3 | 4-5 | 1 | 3 | —— | 1 | 6 | —— |
| 3.2mm V-2 | 1 | —— | —— | 1 | 2-3 | 4-5 | 1 | 3 | —— | 1 | 6 | —— | |
| Remark | Some fillers will affect flame retardancy(such as calcium carbonate, magnesium carbonate, etc.)It is recommended to add barium sulfate, mica powder, glass beads, etc. Talc powder should be of high silicon content. The combination of strong shearing screws is not recommended for screw shearing; There is no vacuum or low vacuum in the extrusion process |
||||||||||||
Manufacturing Facility in XUSEN
Professional V0 Flame Retardant Masterbatch For PP manufacturer in China, We currently achieved an annual production capacity of 12,000 tons. We can also OEM, simply wholesale V0 Flame Retardant Masterbatch For PP direct from manufacturer. We have our own production workshops and warehouses, equipped with complete production and quality inspection equipment.
